Tripp Lite by Eaton UPS Smart 5000VA 4000W Rackmount AVR 208V/120V Pure Sign Wave 5kVA USB DB9 6URM — SMART5000RT3U
Tripp Lite by Eaton UPS Smart 5000VA 4000W Rackmount AVR 208V/120V Pure Sign Wave 5kVA USB DB9 6URM — SMART5000RT3U is backordered and will ship as soon as it is back in stock.
We can still source this. A solutions architect will confirm availability, pricing, and lead time — usually within one business day.
Description
Description
Tripp Lite's line-interactive SMART5000RT3U UPS System protects server, networking or telecommunications equipment from blackouts, voltage fluctuations and surges in a compact tower/rackmount housing. Large capacity 5000VA/4000W power module converts raw 208V AC input to fully regulated dual output 208/120 voltage for simultaneous protection of both high- and low-voltage equipment loads. True sine wave output at all times offers guaranteed compatibility with all equipment types. Includes 14 outlets, 8 of which can be individually reset via software interface to selectively reboot remote equipment or shed less critical loads to extend battery runtime for more critical equipment. Includes slot for internal SNMP/web card, plus two DB9 and two USB enhanced monitoring ports for unattended shutdown, remote control and monitoring of UPS system and power data. 2 Year Warranty standard. 3 Year Warranty with product registration.
- NEMA L6-30P input; 10 5-15R, 2 5-15/20R, 1 L6-30R & 1 L14-30R outlets
- Expandable runtime; 8 single-outlet switched output load banks
- USB, Serial, EPO & optional SNMP/Web card monitoring options
- 208 & 120V output during brownouts to 151V and overvoltages to 260V
- 5kVA / 5000VA / 4000W line interactive 6U rack/tower UPS; Sine wave output
Specifications
Specifications
-
Product TypeLine-interactive UPS
-
Product LineSmartPro
-
Country of OriginChina
-
Limited Warranty3 Year
-
Cord Length10 ft
-
Hot SwappableYes
-
Rack Height6U
-
Network ManagementSNMP Manageable
-
Input Voltage220 V AC
-
Waveform TypeSine Wave
-
Output Voltage208 V AC
-
Transfer Time4 ms
-
Typical Battery Recharge Time4 Hour
-
USBYes
-
Battery ChemistryLead Acid
-
Plug/Connector TypeNEMA L6-30P
-
Backup/Run Time (Full Load)16 Minute
-
Package ContentsSMART5000RT3U UPS SMART5000RT3U UPS System BP48V60RT3U battery pack PowerAlert Software and cabling Mounting hardware Instruction manual with warranty information
-
Product ModelSMART5000RT3U
-
Maximum Operating Temperature104°F (40°C)
-
Receptacle TypeNEMA 5-20R,NEMA L14-30R,NEMA 5-15R,NEMA L6-30R
-
Receptacle Detail2 x NEMA 5-20R,1 x NEMA L14-30R,10 x NEMA 5-15R,1 x NEMA L6-30R
-
ManufacturerTripp Lite by Eaton
-
Battery Life6 Year
-
Backup/Run Time (Half Load)38 Minute
-
AlarmOn Battery,Overload,Low Battery
-
Status Indicators5 front panel LEDs - Green 5 front panel LEDs - Green POWER LED, Green VOLTAGE CORRECTION LED, 3 color BATTERY CHARGE LED, 3 color OUTPUT LOAD LED, red BATTERY WARNING LED
-
Manufacturer Website Addresshttps://tripplite.eaton.com/
-
Load Capacity (VA)5000 VA
-
Load Capacity (Watt)4000 W
