Cyberpower  |  SKU: OL1000RTXL2UN  |  UPC: 649532621910
New arrival

CyberPower OL1000RTXL2UN Smart App Online UPS Systems — OL1000RTXL2UN

Regular price $1,500.00 USD
Shipping calculated at checkout.


Request a quote for this item

Volume or contract pricing? Get a written quote with confirmed lead time.

Description

Prevent business interruptions and safeguard mission-critical enterprise network equipment.

The CyberPower OL1000RTXL2UN is a rack/tower UPS with double conversion topology. It provides sine wave output to critical applications and equipment that require seamless power correction. The Extended Battery Module (EBM) expands runtime, and Fast Charge Technology restores full backup power faster. This model comes with an extendable LCD control panel, Smart Battery Management charging technology, and energy-saving GreenPower UPS™ ECO Mode.

The OL1000RTXL2UN offers generator compatibility and delivers clean AC power with zero transfer time. A factory installed RM card allows remote management and configuration of the UPS via a standard web browser, command line interface (CLI), or network management system (NMS). Its sine wave output keeps sensitive equipment working by preventing unnecessary shutdowns that can occur with simulated sine wave output.

With a ,400,000 lifetime connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to high quality.

More from the Manufacturer

  • 3 year
  • PowerPanel® Business Edition
  • Warranty:
  • Telephone, Network
  • Management software:
  • Data line surge protection:
  • USB, Serial, RMCARD205, Relay, EPO
  • Monitoring & Management:
  • 8 � NEMA 5-15R
  • Plug type & cord:
  • NEMA 5-15P, 10 ft. cord
  • Outlet types:
  • Output:
  • 100, 110, 115, 120, 125 V ± 2% (configurable)
  • Waveform:
  • Sine Wave
  • Topology:
  • Double-Conversion
  • Power Factor (PF):
  • 0.9
  • Capacity:
  • 1000 VA / 900 W

Specifications

  • Environmentally Friendly
    Yes
  • Rack Height
    2U
  • Country of Origin
    Taiwan
  • Form Factor
    Rack/Tower
  • Limited Warranty
    3 Year
  • Manufacturer
    CyberPower Systems, Inc
  • Energy Star
    Yes
  • Product Series
    Smart App Online UPS
  • Product Color
    Black
  • Product Model
    OL1000RTXL2UN
  • Receptacle Type
    NEMA 5-15R
  • Input Voltage
    120 V AC
  • Network Management
    SNMP Manageable
  • Waveform Type
    Sine Wave
  • Receptacle Detail
    8 x NEMA 5-15R
  • Typical Battery Recharge Time
    4 Hour
  • Plug/Connector Type
    NEMA 5-15P
  • Serial Port
    Yes
  • Battery Chemistry
    Lead Acid
  • Transfer Time
    0 ns
  • Network (RJ-45)
    Yes
  • Backup/Run Time (Full Load)
    7.40 Minute
  • Replaceable Battery
    Yes
  • Battery Capacity
    9000 mAh
  • Input Voltage Range
    100 V AC - 125 V AC
  • Backup/Run Time (Half Load)
    20 Minute
  • Battery Characteristics
    Sealed
  • Package Contents
    Smart App Online OL1000RTXL2UN 1000VA Rack/Tower UPSUser Manual Registration Card 2 x Rackmount Rails 2 x Rackmount Ears 2 x Hanging Brackets Phone Line Usb Communication Cable Serial Interface Cable (RS-232) 8 x M5x7l Black Flat Head Screws 12 x M5x12l Black Pan Head Screws 6 x M5x6l Silver Pan Head Screws 8 x Plastic Washers 12 x Screw Hole Dust Covers 12 x Rubber Pads And A Software Download Card
  • Number of Batteries
    3
  • Maximum Operating Temperature
    104°F (40°C)
  • Output Voltage
    125 V AC,100 V AC,110 V AC,115 V AC,120 V AC
  • Application/Usage
    Server,Network Device,Storage Device,Network Closet,PBX System,VoIP Phone System,Mission Critical Equipment
  • Product Type
    Double Conversion Online UPS
  • Output Frequency
    60 Hz
  • Overload Protection
    Yes
  • Storage Relative Humidity
    0% - 95%
  • Sound Emission (A-Weighted)
    55 dB(A)
  • Maximum Operating Elevation
    10000 ft
  • EMI/RFI Noise Filter
    Yes
  • USB (HID Compliant) Port
    Yes
  • Battery Size
    12V
  • Dataline Protection
    RJ-11,RJ-45
  • Maximum Storage Elevation
    50000 ft
  • Input Frequency
    70 Hz
  • Software Included
    PowerPanel® Business
  • Storage Temperature
    -4°F (-20°C) - 113°F (45°C)
  • Surge Energy Rating
    1780 J
  • Alarm
    Battery Mode,Low Battery,Overload,UPS Fault
  • EPO Port
    Yes
  • Energy Saving
    ECO Mode Efficiency >94%
  • Status Indicators
    LED Indicators: Power On (White) Line Mode (Green) Battery Mode (Yellow) Bypass Mode (Yellow) Fault (Red) Replace Battery (Red)
  • Thermal Dissipation
    80.30 W
  • Manufacturer Website Address
    https://www.cyberpowersystems.com/
  • Load Capacity (VA)
    1000 VA
