Chief CMS491P2 Ceiling Mount for Projector - White - TAA Compliant — CMS491P2

The CMS491P2 conceals AV equipment above a 2' X 2' ceiling tile to provide a clean professional look for classrooms and conference rooms.

Includes a high-performance, dual gang housing, isolated ground, dual receptacle outlet featuring the SurgeX^® non-sacrificial multi-stage filtration and surge protection system. This protects equipment from disruptive high frequency noise and damage caused by power disturbances.

Chief's powered solutions were co-developed with SurgeX, a brand of AMETEK^® Electronic Systems Protection.

• TAA Compliant
• Plenum rated, UL approved in accordance to 2043
• Lightweight construction, one man installation
• Ships with speed connect installation hardware
• 25 lbs (11 kg) per shelf location
• 50 lbs (22 kg) for projector ceiling plate
• Overall weight capacity 100 lbs (45 kg)
• Ships with 1 shelf, 2nd shelf sold separately see CMSUNV1
• Built in ventilation
• AV tray supports a variety of AV components
• 4 nested knockouts for 1-1/4", 1", & �" diameter conduit
• Up to 2 single gang or 1 dual gang outlet
• Inside the plenum box or facing the room
• Detachable power housing can be pre-installed with electricians on site and assembled to the storage boxat a later time
• Drop carriage door improves accessibility and serviceability providing full access to equipment
