APC Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-30R NEMA, SmartSlot, Extended runtime [TAA] — SMX3000RMLVUS
APC Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-30R NEMA, SmartSlot, Extended runtime [TAA] — SMX3000RMLVUS is backordered and will ship as soon as it is back in stock.
We can still source this. A solutions architect will confirm availability, pricing, and lead time — usually within one business day.
APC Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-30R NEMA, SmartSlot, Extended runtime [TAA] — SMX3000RMLVUS is backordered and will ship as soon as it is back in stock.
Description
Description
- Ideal for servers, storage, networking & commercial applications
- Automatic Voltage Regulation keeps output voltage within acceptable user selectable levels
- Add up to 10 external battery packs (SMX120RMBP2U)
- Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown
- User-selectable low voltage setting of 100V-127V
- 2880VA/2700W line interactive pure sine wave 2U rack/tower UPS (rail kit included)
Specifications
Specifications
-
Environmental CertificationRoHS
-
Environmentally FriendlyYes
-
Form FactorRack-mountable
-
Product TypeLine-interactive UPS
-
Rack Height2U
-
TAA CompliantYes
-
Limited Warranty3 Year
-
Energy StarYes
-
ManufacturerSchneider Electric SA
-
Hot SwappableYes
-
Product ColorBlack
-
Cord Length8 ft
-
Product LineSmart-UPS X
-
Product ModelSMX3000RMLVUS
-
Manufacturer Website Addresshttp://www.schneider-electric.com
-
Output Voltage120 V AC
-
Plug/Connector TypeNEMA L5-30P
-
Waveform TypeSine Wave
-
Typical Battery Recharge Time3 Hour
-
Battery ChemistryLead Acid
-
Transfer Time8 ms
-
Backup/Run Time (Full Load)6.30 Minute
-
Number of Battery & Surge Outlets7
-
Surge Energy Rating540 J
-
Input Voltage120 V
-
Receptacle TypeNEMA L5-30P
-
Receptacle Detail1 x NEMA L5-30R,3 x NEMA 5-15R,3 x NEMA 5-20R
-
Package ContentsSmart-UPS X 3000VA Rack/Tower LCD 100-127V TAA CD with software Documentation CD Installation guide Rack mounting brackets Rack mounting hardware Rack mounting support rails Removable support feet Smart UPS signalling RS-232 cable USB cable
-
Input Voltage Range70 V AC - 153 V AC
-
Application/UsageServer,Storage Device,Network Device,POS Terminal,Security System,Communication System,Router,Network Hub,Edge Computing
-
Additional Warranty Information3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available
-
Software IncludedPowerchute Serial Edition
-
Load Capacity (Watt)2700 W
-
Load Capacity (VA)2880 VA
